Ultra-thin Lipo Battery Cell 501515 3.7v 70mAh 80mAh Rechargeable Lithium Polymer Batteries

Merknaam:	RESKY
Modelnummer:	LP501515
MOQ:	1000 stuks
Prijs:	Onderhandelbaar
Verpakking:	Papieren doos
Betalingsvoorwaarden:	Western Union,T/T

Gedetailleerde informatie

Productbeschrijving

Gedetailleerde informatie

Plaats van herkomst:

China

Certificering:

MSDS, Un38.3

Model-NR.:

LP501515

Spanning:

Capaciteit:

80mAh

10 STUKS

Cyclus leven:

500cycles

Garantie:

12 maanden

kleur:

Zilver, blauwe PVC

Specificatie:

5*15*15mm

HS-code:

8507600090

Levering vermogen:

100000 pcs/dag

Levering vermogen:

50000 stcs/dag

Markeren:

Ultra-thin Lipo Battery 501515

3.7v Rechargeable Lithium Polymer Battery

70mAh 80mAh Lipo Battery Cell

Productbeschrijving

Ultra-thin Lipo Battery Cell 501515 3.7V 70mAh/80mAh

Compact rechargeable lithium polymer batteries designed for space-constrained electronic devices requiring reliable power in minimal dimensions.

Technical Specifications

Parameter	Specification
Battery Type	3.7V 80mAh LiPo Battery
Charge Voltage	4.2V
Nominal Voltage	3.7V
Nominal Capacity	80mAh @ 0.2C Discharge
Charge Current	Standard: 0.5C Rapid: 1.0C
Standard Charging Method	0.5C CC charge to 4.2V, then CV charge till current ≤0.05C
Charging Time	Standard: 2.75 hours (Ref.) Rapid: 2 hours (Ref.)
Max Charge Current	1.0C
Max Discharge Current	1.0C
Discharge Cut-off Voltage	2.5V ±0.25V (0.2C)
Operating Temperature	Charging: 0°C ~45°C Discharging: 0°C ~45°C
Storage Temperature	-10°C ~ +45°C
Dimensions	Length: 15±0.5mm (excluding tabs) Width: 15±0.5mm Thickness: 5±0.2mm
Drop Test	1m drop onto concrete twice - No fire, no leakage
Cycle Life	≥500 cycles

Key Advantages

Safety: Ternary lithium polymer technology with built-in circuit protection (overcharge/over-discharge) and environmental compliance
Performance: Low internal resistance, long cycle life (≥80% capacity retention after 300 cycles), no memory effect
Energy Density: Higher capacity in compact size, lightweight and thin design for easy integration

Application Areas

TWS Bluetooth Earphones: Long-lasting power for compact units with ultra-thin design reducing wearing burden
Smart Wearable Devices: Smartwatches, bracelets, AR/VR glasses, and motion trackers
Miniature Medical Devices: Hearing aids, portable monitors, and insulin pumps
Small Electronic Toys: Remote control cars, airplanes, and interactive toys
Microelectronic Devices: Smart cards, miniature cameras, sensors, wireless remotes, and small lighting

Product Images
